All-New, BallisTec Carbon, internal downtube battery, integrated cable routing w/ Switchplate, dropout/axle spacing 135mm, SAVE, T47, flat mount disc, integrated seat binder
All-New, BallisTec Carbon, SAVE, 1-1/8" to 1-1/4" steerer, integrated crown race, 12x100mm Speed Release thru-axle, flat mount disc, internal routing, 55mm offset (S-M) 45mm offset (L)
HollowGram 45 KNØT, Carbon, 20h front, 32h rear, 45mm deep, 21mm ID, tubeless ready
(F) HollowGram KNØT, sealed bearing 12x100 centerlock / (R) ebikemotion X35 250W
DT Swiss Aerolite
Vittoria Rubino Pro Bright Black, 700 x 25c
Not Included
HollowGram, T47 w/ OPI SpideRing, 50/34
FSA T47 MegaEvo, threaded
Shimano HG701, 11-speed
Shimano Ultegra, 11-30, 11-speed
Shimano Dura-Ace Di2, braze-on
Shimano Dura-Ace Di2
Shimano Dura-Ace Di2 hydro disc, 2x11
HollowGram SystemBar SAVE, Carbon, 8 deg. pitch adjust
MAHLE ebikemotion X35 250W
Prologo One Touch
MAHLE ebikemotion X35 250Wh
HollowGram KNØT, alloy w/ cable cover, -6°
iWoc ONE
Integrated Sealed Bearing, Tapered
MAHLE ebikemotion X35
Shimano Dura-Ace Di2 hydro disc, 160/160mm RT86 rotors
Prologo Dimension NDR, 143mm width, Tirox rails
All-New HollowGram 27 SL KNØT, carbon, 2 bolt clamp, 330mm
SM, MD, LGTechnology Innovation
Speed Shapes
Speed Shapes
The frame features highly truncated airfoil tube shapes that offer the same weight, and equal or better stiffness, than round tubes, but reduce drag by up to 30%.
Clearly Capable
Clearly Capable
The frame is designed to accept larger-volume road tires (28mm tires fit with a full 6mm of clearance on all sides) for extra comfort and capability on all kinds of roads.
The Boost
The Boost
The ebikemotion drive system uses a lightweight 250W rear hub motor and hidden 250Wh battery to provide three levels of "just-right" support. It's there when you need it, nearly imperceptible when you don't.
Intuitive Controller
Intuitive Controller
The integrated top tube controller lets you turn the system on, select your assist level and see your battery charge, all at the touch of a button, keeping your bars clean and uncluttered.
Hidden Cable Routing
Hidden Cable Routing
Unique design routes brake lines through an opening in the front of the headtube for minimal drag and headache-free serviceability.
HollowGram SAVE SystemBar
HollowGram SAVE SystemBar
This sleek, integrated handlebar system reduces drag and absorbs shock for more speed and better comfort. The two-piece design offers interchangeability and pitch adjust to fine tune your position.
HollowGram 45 KNØT Wheels
HollowGram 45 KNØT Wheels
Our ultra-fast, low-drag, wide rim profile with a light, versatile 45mm depth. Maintains high aerodynamic efficiency even with big tires.
